VR Guardians can be helpful tools for those of us exploring virtual worlds with immersive headsets – but they’re not always as intuitive as they could be. Let’s face it: the Meta Quest 2 Guardian system faced a lot of backlash for being buggy and unreliable. Fortunately, the Meta Quest 3 Guardian system offers some significant improvements.
Unlike the Meta Quest 2 Guardian, which forced users to constantly redraw boundaries when they moved around or adjusted furniture, the updated Guardian is a lot “smarter.” It can even automatically suggest stationary Guardian settings based on your room space.
Still, setting your Guardian up for the first time can be a little tricky. There are still a bunch of settings to tweak to ensure the best possible experience.
Here, I’ll guide you through each step of configuring your Meta Quest 3 Guardian and share some tips on how to overcome common problems.
What is the Meta Quest 3 Guardian?
The Meta Quest 3 Guardian is a built-in safety feature on Meta headsets that allows users to create “boundaries” in virtual reality. These boundaries appear when you approach the edge of your available playing space, preventing you from bumping into chairs and tables (mostly).
Like many other older headsets, the Meta Quest 2 had a pretty basic Guardian system. Users could place a pre-configured circular boundary around themselves or draw a boundary using the Meta controllers. In either case, when you strayed too close to your boundaries, the Guardian would kick in and show your surroundings through Meta’s black-and-white passthrough feature.
On the other hand, the Meta Quest 3 Guardian is a new “Smart” solution from Meta. The company even promoted this feature before it released its new headset, showing videos of the device using its camera array to scan rooms for users and suggest boundary limitations.
While you might still need to tweak your boundary with your controllers, the overall experience is much more intuitive. Plus, in my opinion (and according to many other users), this system doesn’t seem to encounter quite as many bugs.
Setting Up your Meta Quest 3 Guardian Boundaries
When you load up your Meta Quest 3 for the first time, you’ll be automatically asked to set up your Guardian. You can also configure the settings again (potentially after a factory reset) through Meta’s “Quick Settings” panel. The Quest 3 gives you two boundary options to choose from.
The first is a “Stationary” boundary, intended for using your headset sitting or standing in one place. This is probably the option I’d choose if you’re using your headset for things like VR meetings. The second option is the “Roomscale” boundary.
The Roomscale boundary uses the headset to scan your surroundings, then allows you to draw and adjust boundaries in your physical space. It’s ideal for when you’re moving around while using your headset.
To switch between boundary modes or redraw your boundaries, press the Meta button on your controller to pull up your menu. Then select Quick Settings, followed by Boundary. Once you’ve selected your boundary, you can follow the instructions on the screen to make adjustments.
Managing your Boundary Settings
Once you’ve chosen your Boundary mode, you can adjust your settings by accessing the Universal menu again, selecting Library, then Settings, then Physical space. Choose Create new boundary, and you’ll see a range of options, such as:
- Set floor level: Identify the floor level of your boundary (where your feet are)
- Adjust boundary: Return to the boundary setup to redraw your lines.
- Boundary color: Change the color of your boundary
- Pass-through: Add a double-tap option to the side of your headset for passthrough mode.
- Glanceable boundary: An option that allows you to look down in VR at an angle and see where you are in your assigned space.
- Clear boundary history: Remove all the boundary anchors in the cloud, and on your device for the account you’re using.
You can also adjust your boundary sensitivity and a range of other sensitivity settings. You can choose between “simple” and “advanced” adjustment options for boundary sensitivity. I wouldn’t recommend diving into the advanced settings unless you have a particularly complicated environment.
The other sensitivity settings allow you to control your headset and controller distance sensitivity, which influences how quickly you’re alerted when approaching boundaries. You can also adjust the speed sensitivity of your headset and controllers to determine how you’re alerted when making faster movements at a boundary edge.
Notably, while clearing your boundary history removes anchors from your device and the cloud for your account, it doesn’t remove any “scenes”. To do this, you’ll need to go into your Library click on Settings, then Physical Space, and select Space Setup.
You can choose Manage your Spaces to clear your scenes and spaces. Alternatively, you can clear your physical space history by visiting your Privacy and Safety page, and selecting Device Permissions. Then, click Clear next to Physical Space History.
Using Boundary Space Sense
“Space Sense” is a new Meta Quest 3 Guardian feature that makes the headset a little more effective at keeping you safe in VR. It allows you to see the outlines of objects, people, and even pets that cross the boundaries of a “Roomscale” boundary in VR.
This feature shows you outlines of objects up to 9 feet away as long as they enter your “play space”. You can turn this feature on and off at any time. Just click the Meta button on your Touch controller, and in the Universal Menu, select Quick Settings.
